Steinkjer stabling facility

Photo of Steinkjer Stabling Facility
Photo: Bane NOR
Jump to article

On this page:

Location

Section: Trondheim S–Bodø, Nordlandsbanen.
Distance from Trondheim: 125,5 km.

Contact us

Track table

Track Platform Comments
No. Type Length (m) Passing loop length (m) Extended option (m) Length (m) Height (mm) Width (m)
1 Main track 1870     330 760 5 Side platform.
2 Train track 773 607
3 Stub track 337
4 Other tracks 403 222
5 Other tracks 284 157
6 Stub track 282 170   160,60 760 6

Island platform.

7 Stub track 294
8 Stub track 293
13 Stub track 95 50
14 Stub track 357
15 Stub track 73

Stabling capacity

Track number Stabling length (m) Number of
train slots  (110 m)
Overhead line Service platform Track access by car Toilet disposal Water filling Train heating Train wash Diesel fuelling Compressed air for brakes Comments
3 296 2
4 221 2
5 157 1 X
7 240 2 X X X X
8 245 2 X X X X
9
15

Train heating installations

Installation Location and Capacity
Installation no. Capacity (kVA) Stand no.  Local indentity no.  Serving track no.  Voltage (V) Frequency (Hz) Maximal continuous current (A)
EL-TVA-000171 600
EL-TVA-000172 900

Track plan

Track plan Steinkjer Stabling Facility
Bane NOR

Download the track plan
