Stavanger stabling facility, Paradis

Jump to article

Location

Address

Lagårdsveien 4010 Stavanger

Show directions:

Track					Platform			Comments
No.	Type	Length (m)	Passing loop length (m)	Extended option (m)	Length (m)	Height (mm)	Width (m)
1	Main track	1321	310		257	660/760	11,50	Island platform between tracks 1 and 2.
2	Main track	1214	164
3	Train track	150	160
4	Train track	150	226		183	660	8	Island platform between tracks 4 and 3.
4	Train track	150	226		183	660	8	Island platform between tracks 4 and 3.
4	Train track	150	226		183	660/760	11,50	Island platform.
5	Train track	180	224
6	Stub track	320						From buffer stop 5935 – buffer stop track 1.
7	Main track	2785	160					From buffer stop 5935 – buffer stop track 2.
8	Øvrige spor	100						Port track.
20	Train track	1897,70						From km 597 – railway switch 508.
21	Train track	256
22	Train track	303
25	Stub track	140
26	Stub track	140
601	Stub track	146						Maintenance.
602	Stub track	118						Maintenance.
603	Stub track	118						Maintenance.
604	Stub track	212						Maintenance.
609	Stub track	377,50						Maintenance.
610	Stub track	247,50						Maintenance.
611	Stub track	247,50						Maintenance.
612	Stub track	299						Maintenance.

Track number	Stabling length (m)	Number of train slots (110 m)	Overhead line	Service platform	Track access by car	Toilet disposal	Water filling	Train heating	Train wash	Diesel fuelling	Compressed air for brakes	Comments
20	300	2	X	–	–	X	X	–	X	–	–	Vaskemaskin stenger når utetemperaturen er under 4 °C.
21	260	2	X	–	–	–	–	–	–	–	–
22	320	2	X	X	–	–	–	–	–	–	–
25	174	1	X	–	–	–	–	–	–	–	–
26	174	1	X	–	X	–	–	–	–	–	–

Installation no.	Capacity (kVA)	Stand no.	Local indentity no.	Serving track no.	Voltage (V)	Frequency (Hz)	Maximal continuous current (A)
EL-TVA-000078	1650
EL-TVA-000079	1650
EL-TVA-000142	1800
EL-TVA-000173
EL-TVA-000174
