Eidsvoll stabling facility

Jump to article

Location

Section: Oslo S–Eidsvoll, Gardermobanen.
Distance from Oslo: 67,86 km.

Address

Eilert Smiths vei 1 0975 Oslo

Show directions:

Track					Platform			Comments
Number	Type	Length (m)	Passing loop length (m)	Extended option (m)	Length (m)	Height (mm)	Width (m)
1	Main track	1219			350	600	5	Side platform.
2	Train track	1022,20			240	600	6	Island platform between tracks 2 and 3.
3	Main track	1620,40
4		1321,30			183	550	3	Side platform.
5	Train track	640	485
7	Main track	954,50
8	Main track	1154,80
11	Main track	791,50
12	Main track	224,60
13	Train track	774,70
14	Main track	1665
15	Train track	1326,10
16	Main track	2032,50
20	Stub track	284	225		218	550	2	Service platform.
21	Stub track	177	118		121	550	2	Service platform between tracks 21 and 22.
22	Stub track	177	118		121	550	2	Service platform between tracks 22 and 21.
23	Stub track	573	150
24	Stub track	278	229		219	550	2	Service platform between tracks 24 and 25.
25	Stub track	270	229		219	550	2	Service platform between tracks 25 and 26.
26	Stub track	287	229		219	550	2	Service platform between tracks 26 and 25.
30	Stub track	72	57
31	Stub track	207	32
40	Stub track	282,90			40	760	1	Service platform. Turning point.

Track number	Stabling length (m)	Number of train slots (110 m)	Overhead line	Service platform	Track access by car	Toilet disposal	Water filling	Train heating	Train wash	Diesel fuelling	Compressed air for brakes	Comments
20	225	2	X	X	–	–	–	X	X*	–	–	*Open between 15. April–15. October.
21	118	1	X	X	–	–	–		–	–	–
22	117	1	X	X	X	X	X	X	–	–	–
23	110	1	X	X					–	–	–
24	225	2	X	X	X	X	X	X	–	–	–
25	226	2	X	X	X	X	X	X	–	–	–
26	229	2	X	X	X	X	X	X	–	–	–

Installation		Location and Capacity
Installation no.	Capacity (kVA)	Stand no.	Local indentity no.	Serving track no.	Voltage (V)	Frequency (Hz)	Maximal continuous current (A)
EL-TVA-000112	2000
EL-TVA-000113	2000
EL-TVA-000114	2000
